GitHub Actions make CI/CD simple and powerful, but securely accessing AWS resources from runners requires care. Traditionally, this meant storing long-lived AWS access keys as GitHub secrets, a practice with obvious security risks. With OpenID Connect (OIDC), we now have a modern, keyless authentication method between GitHub Actions and AWS.
In this technical deep-dive, we’ll explore how GitHub OIDC works with AWS, how to set it up, and how to integrate it with OpenTofu/Terraform for infrastructure deployment.
Understanding the OIDC Flow
Before diving into implementation, let’s understand how GitHub OIDC authentication works with AWS:
-
Token Generation: When a GitHub Action runs, GitHub automatically generates a JSON Web Token (JWT) that contains information about the workflow, repository, and execution context.
-
Token Exchange: The GitHub Action presents this JWT to AWS STS (Security Token Service) via the OIDC identity provider.
-
Token Validation: AWS validates the JWT signature and claims against the configured OIDC identity provider and IAM role trust policy.
-
Role Assumption: If validation succeeds, AWS STS issues temporary credentials for the specified IAM role.
-
Resource Access: The GitHub Action can now use these temporary credentials to access AWS resources.
Setting Up the AWS OIDC Identity Provider
First, we need to create an OIDC identity provider in AWS that trusts GitHub’s token issuer.
Using AWS CLI
aws iam create-open-id-connect-provider \
--url https://token.actions.githubusercontent.com \
--client-id-list sts.amazonaws.com \
--thumbprint-list 6938fd4d98bab03faadb97b34396831e3780aea1
Using Terraform/OpenTofu
resource "aws_iam_openid_connect_provider" "github" {
url = "https://token.actions.githubusercontent.com"
client_id_list = [
"sts.amazonaws.com",
]
thumbprint_list = [
"6938fd4d98bab03faadb97b34396831e3780aea1"
]
tags = {
Name = "GitHub OIDC Provider"
}
}
Important Notes:
- The thumbprint
6938fd4d98bab03faadb97b34396831e3780aea1
is GitHub’s current root CA thumbprint - The client ID must be
sts.amazonaws.com
for AWS STS integration - The URL must be
https://token.actions.githubusercontent.com
Creating the IAM Role
Now we need to create an IAM role that GitHub Actions can assume. The key is configuring the trust policy to validate specific JWT claims.
Trust Policy Configuration
{
"Version": "2012-10-17",
"Statement": [
{
"Effect": "Allow",
"Principal": {
"Federated": "arn:aws:iam::ACCOUNT-ID:oidc-provider/token.actions.githubusercontent.com"
},
"Action": "sts:AssumeRoleWithWebIdentity",
"Condition": {
"StringEquals": {
"token.actions.githubusercontent.com:aud": "sts.amazonaws.com"
},
"StringLike": {
"token.actions.githubusercontent.com:sub": "repo:your-org/your-repo:*"
}
}
}
]
}
Complete IAM Role with Terraform/OpenTofu
data "aws_caller_identity" "current" {}
# IAM role for GitHub Actions
resource "aws_iam_role" "github_actions_role" {
name = "OpenTofuExecutionRole"
assume_role_policy = jsonencode({
Version = "2012-10-17"
Statement = [
{
Effect = "Allow"
Principal = {
Federated = "arn:aws:iam::${data.aws_caller_identity.current.account_id}:oidc-provider/token.actions.githubusercontent.com"
}
Action = "sts:AssumeRoleWithWebIdentity"
Condition = {
StringEquals = {
"token.actions.githubusercontent.com:aud" = "sts.amazonaws.com"
}
StringLike = {
"token.actions.githubusercontent.com:sub" = [
"repo:your-org/your-repo:ref:refs/heads/main",
"repo:your-org/your-repo:ref:refs/heads/develop",
"repo:your-org/your-repo:pull_request"
]
}
}
}
]
})
tags = {
Name = "GitHub Actions OpenTofu Role"
}
}
# Policy for OpenTofu operations
resource "aws_iam_policy" "opentofu_policy" {
name = "OpenTofuDeploymentPolicy"
description = "Policy for OpenTofu deployments via GitHub Actions"
policy = jsonencode({
Version = "2012-10-17"
Statement = [
{
Effect = "Allow"
Action = [
# S3 permissions for state backend
"s3:ListBucket",
"s3:GetObject",
"s3:PutObject",
"s3:DeleteObject",
# DynamoDB permissions for state locking
"dynamodb:GetItem",
"dynamodb:PutItem",
"dynamodb:DeleteItem",
"dynamodb:DescribeTable",
# EC2 permissions (adjust based on your needs)
"ec2:*",
# IAM permissions (be as restrictive as possible)
"iam:ListRoles",
"iam:ListPolicies",
"iam:GetRole",
"iam:GetPolicy",
"iam:CreateRole",
"iam:AttachRolePolicy",
"iam:DetachRolePolicy",
"iam:DeleteRole",
# Add other AWS services as needed
]
Resource = "*"
}
]
})
}
# Attach policy to role
resource "aws_iam_role_policy_attachment" "github_actions_policy_attachment" {
role = aws_iam_role.github_actions_role.name
policy_arn = aws_iam_policy.opentofu_policy.arn
}
# Output the role ARN for use in GitHub Actions
output "github_actions_role_arn" {
value = aws_iam_role.github_actions_role.arn
description = "ARN of the IAM role for GitHub Actions"
}
Understanding JWT Claims and Conditions
The JWT token from GitHub contains several claims that we can use in our trust policy conditions:
Key JWT Claims
aud
: Alwayssts.amazonaws.com
for AWS integrationsub
: Subject identifier (e.g.,repo:owner/repo:ref:refs/heads/main
)iss
: Issuer, alwayshttps://token.actions.githubusercontent.com
repository
: Repository name (owner/repo
)repository_owner
: Repository ownerref
: Git reference (branch, tag, or PR)actor
: GitHub username that triggered the workflow
Advanced Condition Examples
{
"Condition": {
"StringEquals": {
"token.actions.githubusercontent.com:aud": "sts.amazonaws.com",
"token.actions.githubusercontent.com:repository_owner": "your-org"
},
"StringLike": {
"token.actions.githubusercontent.com:sub": "repo:your-org/*:*"
},
"ForAnyValue:StringEquals": {
"token.actions.githubusercontent.com:ref": [
"refs/heads/main",
"refs/heads/develop"
]
}
}
}
This configuration:
- Restricts access to repositories owned by
your-org
- Allows any repository under the organization
- Only permits deployments from
main
anddevelop
branches
GitHub Actions Workflow Implementation
Now let’s implement the GitHub Actions workflow using the OIDC authentication. The below example uses our TF GitHub Action. You can of course use a different action to complete these steps, or run the individual steps yourself. We find leveraging an action like this though reduces code duplication and ensures consistent implementation of workflows across projects.
Complete Workflow Example
name: Deploy Infrastructure
on:
push:
branches: [main, develop]
pull_request:
branches: [main]
permissions:
id-token: write # Required for OIDC token generation
contents: read # Required to checkout code
jobs:
plan:
runs-on: ubuntu-latest
steps:
- name: Checkout code
uses: actions/checkout@v4
- name: Configure AWS credentials
uses: aws-actions/configure-aws-credentials@v4
with:
role-to-assume: arn:aws:iam::123456789012:role/OpenTofuExecutionRole
role-session-name: github-actions-opentofu-session
aws-region: eu-west-2
# Optional: specify role duration (default: 1 hour, max: 12 hours)
role-duration-seconds: 3600
- name: Verify AWS credentials
run: |
aws sts get-caller-identity
echo "AWS credentials configured successfully"
- name: Validate and Plan
uses: coresolutionsltd/[email protected]
with:
workdir: ./infra
env: prod
steps: validate plan
apply:
runs-on: ubuntu-latest
needs: plan
environment: prod # This environment can have protection rules which requires approval
steps:
- name: Checkout code
uses: actions/checkout@v4
- name: Configure AWS credentials
uses: aws-actions/configure-aws-credentials@v4
with:
role-to-assume: arn:aws:iam::123456789012:role/OpenTofuExecutionRole
role-session-name: github-actions-opentofu-session
aws-region: eu-west-2
# Optional: specify role duration (default: 1 hour, max: 12 hours)
role-duration-seconds: 3600
- name: Verify AWS credentials
run: |
aws sts get-caller-identity
echo "AWS credentials configured successfully"
- name: Apply
uses: coresolutionsltd/[email protected]
with:
workdir: ./infra
env: prod
steps: apply
Advanced Configuration Options
Multi-Environment Setup
For different environments, you can use separate IAM roles:
- name: Configure AWS credentials
uses: aws-actions/configure-aws-credentials@v4
with:
role-to-assume: ${{ github.ref == 'refs/heads/main' &&
'arn:aws:iam::123456789012:role/ProdOpenTofuRole' ||
'arn:aws:iam::123456789012:role/DevOpenTofuRole' }}
role-session-name: ${{ github.run_id }}-${{ github.run_attempt }}
aws-region: eu-west-2
Cross-Account Deployment
For deploying to multiple AWS accounts:
strategy:
matrix:
environment: [dev, staging, prod]
include:
- environment: dev
account_id: "111111111111"
region: "eu-west-1"
- environment: staging
account_id: "222222222222"
region: "eu-west-2"
- environment: prod
account_id: "333333333333"
region: "eu-west-2"
steps:
- name: Configure AWS credentials
uses: aws-actions/configure-aws-credentials@v4
with:
role-to-assume: arn:aws:iam::${{ matrix.account_id }}:role/OpenTofuExecutionRole
role-session-name: deploy-${{ matrix.environment }}-${{ github.run_id }}
aws-region: ${{ matrix.region }}
Security Best Practices
1. Principle of Least Privilege
Always grant the minimum permissions necessary:
# Instead of using wildcard permissions
resource "aws_iam_policy" "restrictive_policy" {
name = "RestrictiveOpenTofuPolicy"
policy = jsonencode({
Version = "2012-10-17"
Statement = [
{
Effect = "Allow"
Action = [
"ec2:DescribeInstances",
"ec2:DescribeSecurityGroups",
"ec2:RunInstances",
"ec2:TerminateInstances"
]
Resource = "*"
Condition = {
StringEquals = {
"aws:RequestedRegion": ["eu-west-1", "eu-west-2"]
}
}
}
]
})
}
2. Branch and Repository Restrictions
Use specific conditions in your trust policy:
{
"Condition": {
"StringEquals": {
"token.actions.githubusercontent.com:aud": "sts.amazonaws.com"
},
"StringLike": {
"token.actions.githubusercontent.com:sub": [
"repo:your-org/infrastructure:ref:refs/heads/main",
"repo:your-org/infrastructure:ref:refs/heads/release/*"
]
}
}
}
3. Session Duration Limits
Set appropriate session durations:
- name: Configure AWS credentials
uses: aws-actions/configure-aws-credentials@v4
with:
role-to-assume: arn:aws:iam::123456789012:role/OpenTofuExecutionRole
role-session-name: session
aws-region: eu-west-2
role-duration-seconds: 1800 # 30 minutes
Troubleshooting Common Issues
1. “No OpenIDConnect provider found” Error
This error occurs when the OIDC provider isn’t properly configured:
# Check if provider exists
aws iam list-open-id-connect-providers
# Verify thumbprint is correct
aws iam get-open-id-connect-provider \
--open-id-connect-provider-arn arn:aws:iam::ACCOUNT:oidc-provider/token.actions.githubusercontent.com
2. “AssumeRoleWithWebIdentity is not authorized” Error
This indicates a trust policy issue. Common causes:
- Incorrect repository name in the subject condition
- Missing or incorrect audience claim
- Branch restrictions not matching the current branch
3. Insufficient Permissions
Monitor CloudTrail logs to identify missing permissions:
{
"eventName": "AssumeRoleWithWebIdentity",
"errorCode": "AccessDenied",
"errorMessage": "User is not authorized to perform: sts:AssumeRoleWithWebIdentity"
}
Conclusion
GitHub OIDC with AWS provides a secure, keyless authentication mechanism that eliminates the need for long-lived credentials. By properly configuring the OIDC identity provider, IAM roles, and trust policies, you can create a robust CI/CD pipeline that follows security best practices.
Key benefits of this approach:
- No secrets management: No AWS access keys to rotate or secure
- Short-lived credentials: Temporary tokens that expire automatically
- Fine-grained access control: Precise conditions based on repository, branch, and other claims
- Audit trail: Complete visibility into authentication and authorization events
The combination of GitHub Actions OIDC and OpenTofu/Terraform creates a powerful, secure infrastructure-as-code deployment pipeline that scales with your needs while maintaining security best practices.
Remember to regularly review and update your IAM policies, monitor CloudTrail logs for suspicious activity, and follow the principle of least privilege when granting permissions to your GitHub Actions workflows.
